CP-PLUS 4MP IP ILLUMAX HYBRID BULLET CAMERA WDR 3.6MM WITH TWO WAY AUDIO (TA41L3B-D-LQ)

Image Sensor
1/2.8 4MP PS CMOS Image Sensor (0.9071 cm)
Effective Pixels
2688 (H) × 1520 (V)
Minimum Illumination
0.001 lux@F1.4 (Color, 30 IRE), 0.0001 lux@F1.4 (B/W, 30 IRE), 0 lux (IR on)
Angle Adjustment
Pan: 0°–360°, Tilt: 0°–90°, Rotation: 0°–360°
Shutter Speed
Auto/Manual 1/3 s–1/100,000 s
RAM
128 MB
ROM
128 MB
White Balance
Auto, Natural, Street lamp, Outdoor, Manual, Regional custom
Gain Control (AGC)
Auto/Manual
Lens Type
Fixed-focal
Max. Aperture
F1.4
Lens Mount
M12
Close Focus Distance
1.5 m
DORI Distance (3.6mm lens)
Detect: 78.0 m, Observe: 31.2 m, Recognize: 15.6 m, Identify: 7.8 m
Lens
3.6 mm Fixed Lens
Back Light Compensation
BLC/ HLC/ WDR(120dB)
Video Compression
Instastream, H.265, H.264, H.264H, H.264B, MJPEG (sub stream only)
IR Number
2 IR LED, 2 Warm light
IR Range
30 meters
Warm Light Range
30 meters
Smart IR
Support
Angle of View (3.6mm)
H: 78°, V: 42°, D: 92°
Smart Search
Works with Smart NVR for intelligent search, event extraction
Resolution
4MP (2688×1520) / (2560×1440), 3MP (2304×1296), 2MP (1920×1080), 1.3MP (1280×960), 720p (1280×720), D1 (704×576 / 704×480), VGA (640×480), CIF (352×288 / 352×240)
Noise Reduction
3D NR
Stream Capability
Triple stream
Frame Rate
Main stream: 4MP (2688×1520) / (2560×1440) @ 1–25/30fps Sub stream 1: 720p, D1, VGA, CIF @ 1–25/30fps Sub stream 2: D1, VGA, CIF @ 1–25/30fps
Video Format
PAL/NTSC
Audio Compression
G.711a, G.711Mu, PCM, G.726
OSD
Camera title, Date & Time
Bit Rate Control
CBR/VBR
Bit Rate
H.265: 3 kbps–6144 kbps, H.264: 8 kbps–6144 kbps
Protocol
SFTP, IPv6, IPv4, DNS, RTCP, NTP, RTP, HTTP, HTTPS, SNMPv3, TLS 1.2, TCP/IP, PPPoE, NFS, UDP, ICMP, IGMP, SSL, DHCP, SMTP, RTSPS, ONVIF (Profile S, G, T), unicast, multicast
Day/Night
Auto(ICR)/Color/B/W
Alarm Event
Network disconnection, IP conflict, illegal access, motion detection, video tampering, audio detection, SMD (human & vehicle), security exception
SMD
Supports human and vehicle classification
Mirror Function
Support
IR Control
Auto, Manual
Ethernet
RJ-45 (10/100 Base-T)
SDK and API
Support
Iris Control
Fixed
Smart Illumination
Support
User/Host
6 users (Total bandwidth: 48 Mbps)
Browser Support
IE, Chrome, Firefox
Image Rotation
0° / 180°
Warranty 2 Years
