MANTRA FINGER PRINT SCANNER FOR AADHAR MFS110 L1

Fingerprint Sensor Type Optical Sensor
Spatial Resolution 500 DPI ± 2%
Platen Area 14.0 mm x 17.0 mm
Image Size 276 x 336 Pixels
Image Grayscale 256 (8-Bit Gray Level)
Light Source Red LED
Approx. Weight 0.140 kg
Approx. Dimension (L x W x H) 61(L) x 91(W) x 54(H) mm
Capture Mode Auto capture with built-in quality check (incorporates NIST quality considerations)
Crypto Operation Hardware base RSA2048 Key Generation, AES-GCM-256, SHA-256, TRNG support
Secure Memory TEE support by the device, secure memory support with key wrapping feature
Secure Boot Secure boot support by the device
Operating Voltage 5V ± 5% (USB Powered Device)
Standby Current 50 mA
Interface USB 2.0
Operating Temperature 0 to 50°C
Storage Temperature 0 to 50°C
Environmental, Health and Safety RoHS
Safety EN/IEC 62368-1, IS 13252 (Part 1)
EMI / EMC Compliance CE, FCC Part 15B
Image Quality Compliance FBI PIV, STQC
IP Rating IP54
Device Driver WHQL certified
Operating System Windows 10 & above OR Android 7 & above
Biometric Data Interchange Format ISO 19794-2 for minutiae & ISO 19794-4 for Image Template in Encrypted PID Data Block
Warranty 1 Year from Mantra Service Centre
