HIKVISION PWA96KITWB CONTROL PANEL ALARM AX PRO KIT WIRELESS

Tag 48
Area 32
Zones 96 (up to 48 PIRCAMs)
Onboard video clips 4
Installer 1
User 46
Admin 1
Voice Prompt Supported
Loudspeaker built in Supported
Tag reader built in Supported
Memory Log stored 5000
Programming tools Hik-Connect/Hik-ProConnect/Web Portal/IVMS4200/Convergence Cloud
Firmware upgrade APP/Web Portal
Arm modes Away/Stay
Automatic Arm/Disarm Timers Supported
Forced Arming with Open Zones Supported
Diagnostics via the APP or Web Supported
ARC protocol SIA DC09(SIA level 2, Contact ID), ISUP, ISAPI (SDK)
Hik-IP Receiver & Hik-IP Receiver Pro (Sur-Gard & Ademco 685) Supported
Video verification and remote control Supported
User APP for operating Supported
Installer APP for programming Supported
Web server for maintenance (offline configuration) Supported
RS232 output Supported
SIM slot Dual
RF transmission Two-way Wireless Communication Support
RF Frequency 433Mhz
Wireless Security Frequency Hopping 128 AES Encryption
3/4G on board Supported
Power supply Built-in power supply
Battery type Built-in on board Battery Li
Battery life span Up to 12 hours at normal temperature
Wired network Supported
Wi-Fi Standard Supported
LEDs Status Arm/Disarm, Alarm, Tamper, Fault, Cloud, Power
Operation temperature -10 °C to +55 °C
Shell material Plastic
Dimension (WxHxD) 170.0 mm (6.7″) x 170.0 mm (6.7″) x 38.6 mm (1.5″)
Weight 557.5 g (19.7 oz)
Color White
Keyfob 48
Wireless sounder 6 (3 internal + 3 external)
Keypad 8 (Including Tag reader)
Wireless Repeater 4
Multi Transmitter 6
PIR Cam Supported
Warranty 2 Years from Hikvision Service Centre
